Customized 5m X 3m Concert Stage Background LED Display Screen Hire Full Color

Product Categories
Shenzhen Vios Electronic Technology Co., Ltd
Contact Now

Customized 5m X 3m Concert Stage Background LED Display Screen Hire Full Color

  • 1
  • 2
  • 3

Brand Name : Viso

Model Number : PH5

Certification : UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin : China

MOQ : 1 Square Meter

Price : Negotiation

Payment Terms : L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA

Supply Ability : 5,000 square meters per month

Delivery Time : 4-6 work days

Packaging Details : Wooden box or Flight case

Usage : indoor

Module size : 160mm * 160mm/320mm*160mm

Brightness : 2500cd / sqm

Power Supply : 5V60A

Screen Dimension : Customized Size

Tube Chip Color : full color

Display Function : video

Warranty : 5 years

Contact Now


Usage:

 Indoor Tube Chip Color: Full Color
Display Function: Video,Photo,Live Video Weight Of Cabinet: 9kg
Cabinet Size: 640*640*80mm Brightness: 2500cd/m2
IC: MBI5020 Power Supply: Meanwell
Refresh Rate: >800Hz Cabinet Material: Die-Casting Aluminum





Smd led display Customized 5m x 3m concert stage background led display

Features
(1) High and adjustable brightness can meet the demands of the changing requirement of Customer
in different environments.
(2) No mosaic due to excellent flatness and nice uniformity of light-emitting.
(3) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change
largely in the range.
(4) High density make the images softer and vivider.
(5) Single-lamp maintenance with low cost.
(6) Good heat dissipation capability because of the unique design of vent fan (liking shutter).
(7) Environmental-friendly and energy-saving.
Applications
Widely used in indoor environment such as municipal mansion, enterprise hall, show room, cinema,
stage, etc.
Specifications

Pixel Information Pixel Pitch 5mm
Pixel Density 40000 Pixels / m2
Pixel Configuration full color video
LED Wavelength Red: 615 nm - 635 nm
Green: 520 nm - 535 nm
Blue: 465 nm - 475 nm
LED Module Module Size(mm) 160× 160mm
Module Resolution 32× 32mm
Cabinet Cabinet Size(mm) 640×640×80
Cabinet Resolution 128× 128
Total QYT Module Per Cabinet 4×4
Cabinet Weight 24 kg/m2
Cabinet Material Die-casting Aluminum LED Display
Power Input Voltage 100-240V AC, 50/60Hz
Max Power Consumption 1100 Watt/m2
Avg. Power Consumption 650 Watt/m2
Brightness ≥2000cd/m2
Brightness Uniformity Luminance Discrepancy < 5%
Best Viewing Angle Horizontal:140°,Vertical:140°
Viewing Distance 5 - 150 meters
Ambient Conditions Temperature Range Working:-20deg. to +60deg
Operating Humidity 10%90%RH
Ingression Protection Grade IP40
Processing Scanning Mode 1/8 scanning
Refresh Frequency 600-1200HZ, Adjustable(depends on control system)
Signal Input DVI, Composite Video for Live Video
Supported Networking Through LAN/WAN, RS 232/RS485
Controller Linsn or Nova
